CWWK Mini PC Fanless Industrial i5-6200U, 2X RS232/RS485 COM, 2 x Gigabit LAN, Micro Embedded Mini Computer Box, NO RAM/SSD/OS, DDR4, NVMe, SIM, SATA, Mini-PCIe, HD, VGA, 6USB

Marca: CWWK
Sistema operativo: No OS, Press Delete repeatedly upon power-on to enter BIOS for testing
Modelo de CPU: Core i5 6200U
Velocidad de CPU: 2,3 GHz
Tamaño de memoria caché: 3 MB
Descripción de la tarjeta gráfica: Integrado
Usos específicos del producto: Educativo, Profesional
Tipo de diseño de ordenador personal: Mini PC
Nombre del modelo: CWWK-2L
Componentes incluidos: Antennas, Mini PC Unit, Power Adapter, SATA cable, Screws

- [i5-6200U & OS Flexibility] Powered by an i5-6200U (2C/4T, up to 2.80GHz, 3MB Cache) balancing processing power and fanless thermal design for stable PLC automation. SSD variants come pre-loaded with Win11 Pro (Unactivated, for out-of-the-box testing). Fully supports Legacy Boot (CSM) and UEFI, engineered to run custom Win10/11 LTSC, Win-Embedded IoT, and Linux
- [Dual LAN & Dual COM Serial] Equipped with 2x RTL8111H Gigabit LAN, supporting Link Aggregation and Network Isolation. Features 2x DB9 COM ports (Default RS232, jumper-configurable to RS485), ideal for PLC, CNC, and field device communication. Supports Auto Power On (AT/ATX jumper-controlled), WOL, PXE, and Hardware WDT for auto-reset, ensuring unattended reliability
- [DDR4 Memory & Versatile I/O] Features 1x SO-DIMM slot supporting up to 32GB 2133MHz DDR4 for heavy industrial multi-tasking. Includes 4x USB 3.0, 2x USB 2.0, and 1x 2x7 Pin TPM 2.0 header. Dual display support via HD1.4 (up to 4K) and VGA. Equipped with a 3.5mm Audio port and a dedicated Clear CMOS jumper for easy maintenance
- [Wireless Network & Flexible Storage] Pre-installed with a WiFi module (antennas included). The Mini-PCIe slot (with SIM slot, supporting PCIe/USB2.0) can alternatively be replaced for 4G/LTE expansion. Features 1x M.2 2280 NVMe/SATA slot and 1x SATA 3.0 port for dual-drive storage (cable included). Supports VESA and rugged embedded wall-mount
- [24/7 Fanless Chassis & Reliability] The fanless rugged chassis ensures silent, dust-proof operation and 24/7 non-stop reliability. Engineered for harsh industrial environments, it supports an extreme operating temperature range of -10 to 60℃. All units undergo rigorous factory testing. We provide an English electronic manual and official technical support from CWWK
